Form

φ22

Installation form

flush-mounted

Detection distance

7mm

Setting distance

0-5.6mm

NPN 3-wire/4-wire

NO

CLJ-B22M-7ANA

NC

CLJ-B22M-7ANB

N+C

CLJ-B22M-7ANC

PNP 3-wire/4-wire

NO

CLJ-B22M-7APA

NC

CLJ-B22M-7APB

N+C

CLJ-B22M-7APC

Supply voltage

10-30VDC

Current consumption

≤15mA

Output current

≤200mA

Output voltage drop

≤1.5V

Response frequency

≤400Hz

 DC 2-wire

NO

CLJ-B22M-7ALA

NC

CLJ-B22M-7ALB

Supply voltage

 10-30VDC

Current consumption

≤1mA

Output current

≤50mA

Output voltage drop

≤5V

Response frequency

≤200Hz

 AC 2-wire

NO

CLJ-B22M-7GKA

NC

CLJ-B22M-7GKB

Supply voltage

 90-250VAC

Current consumption

≤2mA

Output current

≤300mA

Output voltage drop

≤8V

Response frequency

≤25Hz

Repeatability

<1%

Output indicator

Red LED

Environmental temperature

-25℃-+75℃

Environmental humidity

35-95%RH

Shell material

Nickel-copper alloy

Connection method

2m cable

Protection class

IP67
