CLJ-E Flat Proximity Sensor CLJ-E35 Flat Mount Proximity S...

● Inductive proximity sensors detect metal.

●Flatmounting shape φ35mm, plastic case, 2m lead.

● Non-buried, detection distance 15mm.

●NPN, PNP, DC two-wire output.

●Adoption of a dedicated IC torealize excellent anti-interference performance.

● Red LED indicator shows the working status of thesensor.

● High detection accuracy and fast response time.

● With polarity protection and short-circuit protection.

● Long life and high reliability.

●Widely used in all kinds of machinery, automationequipment positioning, limit, detection and so on.


Online Consultation

Form

E35

Installation form

Unburied

Detection distance

15mm

Setting distance

0-12mm

NPN 3-wire/4-wire

NO

CLJ-E35-15ANA

NC

CLJ-E35-15ANB

N+C

CLJ-E35-15ANC

NPN 3-wire/4-wire

NO

CLJ-E35-15APA

NC

CLJ-E35-15APB

N+C

CLJ-E35-15APC

Supply voltage

10-30VDC

Current consumption

≤15mA

Output current

≤200mA

Output voltage drop

≤1.5V

Response frequency

≤500Hz

DC 2-wire

NO

CLJ-E35-15ALA

NC

CLJ-E35-15ALB

Supply voltage

 10-30VDC

Current consumption

≤1mA

Output current

≤50mA

Output voltage drop

≤5V

Response frequency

≤100Hz

Repeatability

<1%

Output indicator

Red LED

Environmental temperature

-25℃-+75℃

Environmental humidity

35-95%RH

Housing material

ABS engineering plastics

Connection method

2m cable

Protection class

IP67
