CLJ-F Small Size Proximity Sensor CLJ-F10-U Small Size Proximity...

● Inductive proximity sensors detect metal.

● Ultra-small volume shape □ 10 x 10mm, plastic case, 2 meter lead.

●Unburied, top sensing, detectiondistance 3mm.

●NPN, PNP, DC two-wire output.

●Adoption of dedicated IC to realizeexcellent anti-interference performance.

● Red LED indicator shows the working status of thesensor.

● High detection accuracy and fast response time.

● With polarity protection and short-circuit protection.

● Long life and high reliability.

●Widely used in all kinds of machinery, automationequipment positioning, limit, detection, etc..

Online Consultation

Form

F10

Installation form

Unburied

Detection distance

2.5mm

Setting distance

0-2mm

NPN 3-wire

NO

CLJ-F10-3UANA

NC

CLJ-F10-3UANB

N+C

 ------

NPN 3-wire

NO

CLJ-F10-3UAPA

NC

CLJ-F10-3UAPB

N+C

 ------

Supply voltage

10-30VDC

Current consumption

≤15mA

Output current

≤200mA

Output voltage drop

≤1.5V

Response frequency

≤1000Hz

DC  2-wire

NO

CLJ-F10-3UALA

NC

CLJ-F10-3UALB

Supply voltage

 10-30VDC

Current consumption

≤1mA

Output current

≤50mA

Output voltage drop

≤5V

Response frequency

≤200Hz

Repeatability

<1%

Output indicator

Red LED

Environmental temperature

-25℃-+75℃

Environmental humidity

35-95%RH

Shell material

ABS engineering plastics

Connection method

2m cable

Protection class

IP67
