CLJ-R Ring Proximity Sensor CLJ-R10-G Ring Proximity Senso...

● Inductive proximity sensors detect metal.

●Ringaperture φ10mm, plastic housing, M12 connector.

●Non-buried type, minimum detectable metal bodyφ0.5mm.

●NPN, PNP output.

●Adoption of dedicated IC to realizeexcellent anti-interference performance.

● Red LED indicator shows the working status of thesensor.

● High detection accuracy and fast response time.

● With polarity protection and short-circuit protection.

● Long life and high reliability.

●Detectionof tiny metal objects, springs, screws, nuts, washers, iron beads, etc., aswell as fracture detection of continuous metal wires.


Online Consultation

Form

R10-G

Installation form

Unburied

Detection distance

φ10mm hole diameter

Minimum detector

φ0.5mm

NPN 3-wire

NO

CLJ-R10-10ANA-G

NC

CLJ-R10-10ANB-G

N+C

PNP 3-wire

NO

CLJ-R10-10APA-G

NC

CLJ-R10-10APB-G

N+C

Supply voltage

10-30VDC

Current consumption

≤15mA

Output current

≤200mA

Output voltage drop

≤1.5V

Response frequency

≤2000Hz

Repeatability

<1%

Output indicator

Red LED

Environmental temperature

-25℃-+75℃

Environmental humidity

35-95%RH

Shell material

PBT

Connection method

M12 connector

Protection class

IP67
