CLJ-R Ring Proximity Sensor CLJ-R21 Ring Proximity Sensor

● Inductive proximity sensors detect metal.

●Ringaperture φ21mm, plastic housing, 2 meterconnection.

●Non-buried type, minimum detectable metal bodyφ0.5mm.

●NPN, PNP output.

●Adoption of dedicated IC to realizeexcellent anti-interference performance.

● Red LED indicator shows the working status of thesensor.

● High detection accuracy and fast response time.

● With polarity protection and short-circuit protection.

● Long life and high reliability.

●Detectionof tiny metal objects, springs, screws, nuts, washers, iron beads, etc., aswell as fracture detection of continuous metal wires.

Online Consultation

Form

R21

Installation form

Unburied

Detection distance

φ21mm hole diameter

Minimum detector

φ1mm

NPN 3-wire

NO

CLJ-R21-21ANA

NC

CLJ-R21-21ANB

N+C

PNP 3-wire

NO

CLJ-R21-21APA

NC

CLJ-R21-21APB

N+C

Supply voltage

10-30VDC

Current consumption

≤15mA

Output current

≤200mA

Output voltage drop

≤1.5V

Response frequency

≤2000Hz

Repeatability

<1%

Output indicator

Red LED

Environmental temperature

-25℃-+75℃

Environmental humidity

35-95%RH

Shell material

PBT

Connection method

2m cable

Protection class

IP67

CLJ-R Ring Proximity Sensor ( 0 )
