CLJ-A Threaded Cylindrical Proximity Sensor CLJ-A12 Threaded Cylindrical P...

●Inductive proximity sensors detect metal.

●M12 thread cylindrical,nickel-copper alloy housing, 2m lead.

●Non-buried type, detection distance 4mm.

●NPN, PNP, DC 2-wire, AC 2-wire, AC/DC 2-wire output.

●Using special IC toachieve excellent anti-interference performance.

●Red LED indicator can showthe working status of the sensor

●High detection accuracy and fast responsespeed.

●With polarity protection and short circuit protection.

●With long lifeand high reliability.

●Widely used in all kinds of machinery, automationequipment positioning, limit, detection, etc.

Online Consultation

Type

M12×1

Mounting

Unburied

Detection distance

4mm

Setting distance

0-3.2mm

NPN3-wire/4-wire

NO

CLJ-A12-4ANA

NC

CLJ-A12-4ANB

N+C

CLJ-A12-4ANC

PNP 3-wire/4-wire

NO

CLJ-A12-4APA

NC

CLJ-A12-4APB

N+C

CLJ-A12-4APC

Supply voltage

10-30VDC

Current consumption

≤15mA

Output current

≤200mA

Output voltage drop

≤1.5V

Response frequency

≤400Hz

DC2-wire

NO

CLJ-A12-4ALA

NC

CLJ-A12-4ALB

Supply voltage

10-30VDC

Current consumption

≤1mA

Output current

≤50mA

Output voltage drop

≤5

Response frequency

≤200Hz

AC2-wire

NO

CLJ-A12-4GKA

NC

CLJ-A12-4GKB

Supply Voltage

90-250VAC

Current consumption

≤2mA

Output current

≤300mA

Output voltage drop

≤8V

Response frequency

≤25Hz

AC/DC2-wire

NO

CLJ-A12-4HMA

NC

CLJ-A12-4HMB

Supply voltage

20-250VAC/DC

Repeat accuracy

＜1%

Output indicator

Red LED

Ambient temperature

-25℃-+75℃

Ambient humidity

35-95%RH

Shell material

Nickel-copper alloy

Connection method

2m cable

Protection degree

IP67
