CLJ-A Threaded Cylindrical Proximity Sensor CLJ-A30M Threaded Cylindrical ...

● Inductive proximity sensors detect metal.

● Cylindrical M30 threads, nickel-copperalloy housing, 2meter leads.

●Buried type, detection distance 10mm.

●NPN, PNP, DC 2-wire, AC 2-wire, AC/DC 2-wire outputs.

●Adoption of a dedicated IC to realizeexcellent anti-interference performance.

● Red LEDindicator to show the working status of the sensor.

● Highdetection accuracy and fast response time.

● Withpolarity protection and short-circuit protection.

● Long lifeand high reliability.

●Widely used in all kinds of machinery, automation equipmentpositioning, limit, detection and so on.

Online Consultation

Form

M30×1

Installation form

flush-mounted

Detection distance

10mm

Setting distance

0-8mm

NPN 3-wire/4-wire

NO

CLJ-A30M-10ANA

NC

CLJ-A30M-10ANB

N+C

CLJ-A30M-10ANC

PNP 3-wire/4-wire

NO

CLJ-A30M-10APA

NC

CLJ-A30M-10APB

N+C

CLJ-A30M-10APC

Supply voltage

10-30VDC

Current consumption

≤15mA

Output current

≤200mA

Output voltage drop

≤1.5V

Response frequency

≤200Hz

DC 2-wire

NO

CLJ-A30M-10ALA

NC

CLJ-A30M-10ALB

Supply voltage

 10-30VDC

Current consumption

≤1mA

Output current

≤50mA

Output voltage drop

≤5V

Response frequency

≤100Hz

AC 2-wire

NO

CLJ-A30M-10GKA

NC

CLJ-A30M-10GKB

Supply voltage

 90-250VAC

Current consumption

≤2mA

Output current

≤300mA

Output voltage drop

≤8V

Response frequency

≤25Hz

AC/DC 2-wire

NO

CLJ-A30M-10HMA

NC

CLJ-A30M-10HMB

Supply voltage

20-250VAC/DC

Repeatability

<1%

Output indicator

Red LED

Environmental temperature

-25℃-+75℃

Environmental humidity

35-95%RH

Housing material

Nickel-copper alloy

Connection method

2m cable

Protection class

IP67
