CCJ-Y Capacitive Pipeline Level Proximity Sensor CCJ-Y13 Capacitive Pipeline L...

● Capacitive pipe level sensorsdetect liquids in containers through non-metallic pipe walls.

● Pipeline type, secured to the pipeline bytie-wraps.

●Applicable pipe diameter φ8-11mm.

●NPN, PNP, AC two-wire output.

●Adoption of dedicatedIC to achieve excellent anti-interference performance.

● Red LED indicator shows the working statusof the sensor.

● High detection accuracy and fast responsetime.

● With sensitivity adjustmentfunction.

● With polarity protection and short-circuitprotection.

● Long life and high reliability.

●Positioning, limiting and detection ofautomated equipment.

●Widelyused in food, packaging, automated machinery, liquid level control, etc.

Online Consultation

form		Y13
Installation form		Unburied
NPN 3-wire	NO	CCJ-Y13-13ANA
	NC	CCJ-Y13-13ANB
PNP 3-wire	NO	CCJ-Y13-13APA
	NC	CCJ-Y13-13APB
Applicable pipe diameter		φ8-11mm
Applicable wall thickness		Less than 1.5mm
Pipe material objects		Plastic, glass, ceramic and other non-metallic materials
Repeatability		±0.2mm
contingency		0.6-5mm
Detecting objects		fluids
Supply Voltage		10-30VDC
Current consumption		≤15mA
Output Current		≤200mA
Output Voltage Drop		≤1.5V
response frequency		≤50Hz
Adjustment method		Multi-turn potentiometer adjustment
Output indicator		red LED
environmental temperature		-10°C-+65°C
Environmental humidity		35-95%RH
Shell material		ABS engineering plastics
connection method		2m cable
protection class		IP67
